New bin out?



Bronze Member
Username: Evilbunz

Post Number: 34
Registered: Oct-07
is there a new bin out for viewsat ultra?? i got the one that came out yesterday but that does not work.


Bronze Member
Username: Thadragun

Kingston, Ontario

Post Number: 29
Registered: Mar-07
Bev just went down Again! :-(


Bronze Member
Username: Evilbunz

Post Number: 35
Registered: Oct-07
so it was working with yesterdays fix, yesterday?


Bronze Member
Username: Thadragun

Kingston, Ontario

Post Number: 31
Registered: Mar-07
Yup, it was. It was working until about 10min ago.


Bronze Member
Username: Silverlion80

Post Number: 76
Registered: Nov-07
YES IT WAS NOT ANYMORE
WAIT FOR NEW BIN AGAIN ......


Bronze Member
Username: Evilbunz

Post Number: 36
Registered: Oct-07
same with dn?


Bronze Member
Username: Mrsofty

Post Number: 30
Registered: Nov-07
crazy for a new box that works ...www.GetDss.com Cheaper and Cheaper every day ther is a bin problem


New member
Username: Smoke74

Post Number: 5
Registered: Oct-07
JERKS


Silver Member
Username: Oleg1474

Florida Usa

Post Number: 651
Registered: Aug-06
well something this good shouldn't die

pouring over this all evening.

as with the ird to fta work lately to me its the last area of the hobby I need to play with

I am finding the hobby really boring, its never about tv its about doing something new and learning.

and would love to work on the Viewsat & Pansat. for just shits and giggles.

when satfta left/was made to leave the hobby it left a rather large hole, then cc closed. so much is done closed source now. I don't think the advent of the fta has detremented the hobby I just think it hasn't been used to its full potentional. a box we can mess with and the legal providers can NOT write legally. so its only our code to deal with no updates. just wish more was done open source and publically exploiting the hardware having fun.

even the crappiest fta has a cpu and ram that far outruns a echostar Euro/ECM666

I don't own an fta so plan to mess with the echostar Euro/Ecm66 just as a winter play project it probably won't amount to much but atleast have fun trying.


now for an utter NEWBIE question


in page 2 of this thread

to quote O-PHD-2

Quote:
0x7FFFFFFE, the top of memory (because it is signed addressing) , the last few bytes of the Flash (or TSOP for those who didn't know). At that location there will be a jmp to some address close by (as it only allows for 2 bytes). This is common to see amongst all versions.

loc_7FFFFFE7:
7FFFFFE7 272F2F2F20202040 ldc #7FFF0000
7FFFFFEF F6 gcall
.
.
.
7FFFFFFE 6107 j loc_7FFFFFE7

Or something along that lines (as the board will really mess up my formatting).

now shockingly in the E666 bev Euro/Ecm666 tsop I have


Code:
7FFFFFFE 6107this using 7FF80000 as a base offset in hex workshop

now using these to documents

View/C4 Core Instruction Set Reference Manual pdf

View datasheet pdf

I don't see where the j routine is broken down from the 61 or 07 I am and I know this is a bad thing but ASSUMING the 61 is the jump and the 07 is its relative addressing

page 95 of the first pdf


Quote:
j n jump
Code: Function 0
Description: Unconditional relative jump. The destination of the jump is expressed as
a byte offset from the first byte after the current instruction. j 0 causes a breakpoint.
Definition:
if (n = 0)
Take a breakpoint trap
else
Iptr4 u next instruction + n
Areg4 u undefined
Breg4 u undefined
Creg4 u undefined
Error signals: j 0 can cause a breakpoint trap to be signalled.
Comments:
Primary instruction.
Instruction is a descheduling point.
Instruction is a timeslicing point.

so I understand its a primary instruction

now by the View pdf


Code:
Function
code Memory Mnemonic Processor Name Notes
code cycles
0 0X j 5 jump D,Tnow

Quote:
Notes
D Instruction can deschedule
T Instruction can timeslice

I am just trying to understand the nomenclature

am familar with asm and its one of my favourite languages
and have worked on the mostek the intel and motorola processors

and I figure no point going past the first instruction until I understand it. so I probably need to be hit with a clue x 4.

but any takers or pointers?

and yes my 7FFFFFE7 exactly matches what Dave2 posted but I figure as I stated above might as well start off on the right foot.

I love the winter gives time late nights for reading the old threads.

Thank you!! Oleg PHD@usa


oleg
Silver Member
Username: Oleg1474

Florida
usa

Post Number: 630
Registered: Aug-06
Posted on Sunday, December 16, 2007 - 12:32 am:

--------------------------------------------------------------------------------
well still up reading so might as well correct myself on my wrong assumptions

not sure what this dump was from but the relevant code matched and was dissassembled

Code:
e509| from loader.txt found in the sti5518 development on curious contraptions
20 | 7FFFFFE4 20 PFIX 00000000
20 | 7FFFFFE5 20 PFIX 00000000
20 | 7FFFFFE6 20 PFIX 00000000
27 | 7FFFFFE7 27 PFIX 00000007
2F | 7FFFFFE8 2F PFIX 0000007F
2F | 7FFFFFE9 2F PFIX 000007FF
2F | 7FFFFFEA 2F PFIX 00007FFF
20 | 7FFFFFEB 29 PFIX 0007FFF9
20 | 7FFFFFEC 22 PFIX 007FFF92
20 | 7FFFFFED 22 PFIX 07FFF922
40 | 7FFFFFEE 44 LDC 7FFF9224
F6 | 7FFFFFEF F6 GCALL_0006
F4 | 7FFFFFF0 80 ADC 00000000
F1 | 7FFFFFF1 E0 STNL 00000000
FF | 7FFFFFF2 FF OUTWORD_000F
7F | 7FFFFFF3 7F LDL 0000000F
A0 | 7FFFFFF4 A4 CJ 00000004 (7FFFFFF9)
F1 | 7FFFFFF5 DD STL 0000000D
FF | 7FFFFFF6 FF OUTWORD_000F
7F | 7FFFFFF7 7F LDL 0000000F
01 | 7FFFFFF8 00 J 00000000 (7FFFFFF9)
00 | 7FFFFFF9 02 J 00000002 (7FFFFFFC)
00 | 7FFFFFFA 00 J 00000000 (7FFFFFFB)
00 | 7FFFFFFB 80 ADC 00000000
20 | 7FFFFFFC 20 PFIX 00000000
20 | 7FFFFFFD 20 PFIX 00000000
61 | 7FFFFFFE 61 NFIX FFFFFFFE
07 | 7FFFFFFF 07 J FFFFFFE7 (7FFFFFE7)any hints truely appreciated so is it working in nibbles or bytes. just talking to myself laugh. will keep reading in the morning, anyway thought I'd post to keep the thread alive.
the 0 at 7FFFFFFF 07 I understand the 7 puzzles me but more when I wake.


--------------------------------------------------------------------------------
Thanks...


Bronze Member
Username: Jack_meoff

Post Number: 85
Registered: Nov-07
