Need some help



Gold Member
Username: Dakangofkrunk16

Boca Raton, Florida

Post Number: 1689
Registered: May-07
ok so i'm gonna get a 2009 Nissan Altima Coupe. It has a GPS touch screen double din headunit. I am not gonna change this out, cause it has voice activation and a bunch of other cool features..

I plan on getting a
15inch Audiopulse Axis
AQ 2500d

What will i need to hook this up to the factory headunit.. Is it possible

I do not plan on upgrading speakers, it has 9 speakers and 2 subwoofers i think, It is a Bose system so no point in replacing them i just want some thump.. The trunk is 7.8 cuft so im tryin to figure out how im gonna do this, but thats for another thread..


Thanks for the help here are pics

Upload
Upload
Upload


Platinum Member
Username: Nyyfan13

Yanks Fan USA

Post Number: 10859
Registered: Jul-06
Electrical upgrades?


Gold Member
Username: Bonhamd

Traverse City, MI

Post Number: 1596
Registered: Nov-07
i dont know any good tips - i always use aftermarket HU

but i will say that your car is badass


Gold Member
Username: Nd4spd18

Philadelphia, PA

Post Number: 9169
Registered: Jul-06
Have fun, interfacing with factory systems is a pain in the azz

Usually you need an adapter module for the premium sound systems like that..... companies like scoshe make them for a varity of cars.... do some research.


Gold Member
Username: Dakangofkrunk16

Boca Raton, Florida

Post Number: 1690
Registered: May-07
ok thanks and yes im upgrading electrical system i'n not a noob.. Yea i took this car for test drive and i fell in love


Silver Member
Username: Wickedbass

Nashville, Tn

Post Number: 212
Registered: Jan-08
"Have fun, interfacing with factory systems is a pain in the azz"

^^^x2. Yeah its a pain, but can be done. At least your not dealing with OnStar. From what ive heard thats the absolute worst to interface with.


Gold Member
Username: Van_man

Boston South, MA

Post Number: 4478
Registered: Mar-06
I dont think AQ makes a 2500...you mean a 2200?
And moduales are what you need.


Silver Member
Username: Dlavante

D&L Designs, Daniel USA

Post Number: 141
Registered: Feb-07
shouldnt be that bad if you're just doing a sub amp off the bose h/u. the hardest part is finding witch pin in the harness is the switched 12v. other than that you'll need to run a LOC off of the stock wires. i checked the diagram for that system and it was fairly similar to my audi's bose system and that did take very long to do at all


Silver Member
Username: Dlavante

D&L Designs, Daniel USA

Post Number: 142
Registered: Feb-07
and you're definitly going to want to upgrade that electrical system


Silver Member
Username: Dlavante

D&L Designs, Daniel USA

Post Number: 143
Registered: Feb-07
sick car btw :-) i want one now


Gold Member
Username: Nd4spd18

Philadelphia, PA

Post Number: 9196
Registered: Jul-06
onstar ain't the worst..... they make interface modules for that


The worst if vehicles they dont make anything for


Silver Member
Username: Dlavante

D&L Designs, Daniel USA

Post Number: 145
Registered: Feb-07
mercedes with fiber optic wiring are the worst ive seen. absolutely nothing you can do to them


Gold Member
Username: Zacdavis

Beloit, Wi

Post Number: 1717
Registered: Dec-03
Guys, he doesnt need any interfaces or onstar crap haha, he's only adding a sub amp to the factory HU.

I'd tag the leads off the factory subwoofer for signal to your aftermarket amp.

The biggest problems I end up having with systems like that is the automatic volume leveler. When you turn the stereo up all the way it detects distortion and automatically attenuates the HU's output to the factory amp. When you add subs that are much louder than the factory system it'll only go so loud haha.
A few times I was able to find the mic/sensor and unhook it. You can also encapsulate it with a bag and a roll of tape haha.

Good luck with the system, show us some pics :D


Gold Member
Username: Th3pwn3r

I compensate...

Post Number: 9048
Registered: Jul-06
So you're no longer getting the three 15'' BTLs, three Memphis 4Kws,3 Kinetik HC2400s and installing it in the trunk of your Caprice? Damn, that sucks dude.


Gold Member
Username: Dakangofkrunk16

Boca Raton, Florida

Post Number: 1691
Registered: May-07
where have you been.. i changed that a long time ago when gas went up, and i dont want no Gas Guzzler v6 ... that was like a couple years ago i changed it to the LMS ultra.. but i dont feel like spending so much money and it wont fit in this trunk.. So now one audiopulse Axis 15 on AQ2200d.. sorry 2500 2200 not the same

And yea i know about the electrical system upgrade well aware of that

Big 3
H/O alt

I decided i want a NEW car not a old car that has no warranty and will most likely break down


Thanks for the help guys


Platinum Member
Username: Wingmanalive

A pic is worth 1000 posts!!

Post Number: 19342
Registered: Jun-06
"and i dont want no Gas Guzzler v6 ..."


Wow does that make me feel old.

Years ago if you had a V6 it most certainly had a "baby on board" sign in the window lol. They were considered the "conservative" vehicle back then. Now they're gas guzzlers?


Even today I can't see myself driving a truck with less than 8 cylinders. Nostalgia aside it just doesn't feel right.


$.02.


Gold Member
Username: Dakangofkrunk16

Boca Raton, Florida

Post Number: 1692
Registered: May-07
lol yea paul your old, but thats cool..

Gas has gone down, but still i rather have a L4 then a V6


Gold Member
Username: Southernrebel

Monroe, Louisiana Team Audible...

Post Number: 7169
Registered: Mar-04
Tap into the factory sub in the car's back deck w/ a nice LOC.
Grab a switched 12v in the dash and run it to a relay.

Easy as that.


Bronze Member
Username: Armykyle1

Ms Us

Post Number: 23
Registered: Dec-08
my buddy has the same car, not sure if he has the bose system. hes got 2 diamond D3 10s running off the factory system, it sounds pretty good, i'll ask him about it
